Ozz Shop OZZ XR3 P9″ Arctic Edition

OZZ XR3 P9″ Arctic Edition

Product ID: 88111

OZZ XR3 P9″ Arctic Edition – the next evolution in driving lights. This 220 mm driving light retains the impressive specifications of its predecessor, the XR2 P9″, while showcasing a striking, all-white design that elevates your vehicle’s aesthetics to new heights. Unlike the previous white version, which featured black details within the lamp, the Arctic Edition is almost entirely white, creating a seamless and modern look that blends perfectly with any white or light-colored vehicle.

Featuring OZZ’s characteristic dynamic start-up position light in both white and orange, the XR3 P9″ Arctic Edition brings an impressive visual effect upon ignition. With its boost function, this driving light emits an incredible 10,600 lumens, providing 1 lux at a distance of up to 680 meters. The carefully designed driving beam pattern ensures optimal visibility with both wide and long-range reach, making it ideal for night driving and off-road adventures.

Built with a color temperature of 5000 K, the OZZ XR3 P9″ Arctic Edition delivers comfortable, daylight-like illumination in any conditions, enhancing both safety and driving experience. Upgrade to the XR3 P9” Arctic Edition for superior style and powerful lighting.

Key Features

All White Look

1 lux @ R112: 480 m, boost 680 m

5000 K

Dynamic Position Light

Ref. no 50

Specifications

Type of lamp LED
Type of LED Osram
Pcs LED 16
Voltage 10-35V DC
Theoretical effect (W) 12V 160
Theoretical effect (W) 24V 160
Actual effect (W) 12V R112: 74W, boost: 134W
Actual effect (W) 24V R112: 73W, boost: 130W
Nominal current at 12 V 10.5 A
Nominal current at 24 V 5.2 A
Theoretical lumen (Lm) 15000
Actual lumen (Lm) R112: 7010, boost 10600
1 lux @ (m) R112: 480, boost: 680
Kelvin (K) 5000
IP-class (IP) IP68/IP69K
Beam pattern Driving
Position light dynamic white and amber
Connection 4-pin DT male + female
Cable length (mm) 1000
Material bracket Stainless steel
Material chassi Aluminum
Material lens Polycarbonate
ØxDxH (mm) 220×84,3×210/227
Operating temperature -40 – +60°C
E-mark approval R112, R7
EMC ECE R10
Ref. no. 50
Weight (kg) 2,6
Warranty 5 years
EAN code 7333213101442
