Key Features
9780 Lm
1 lux @ R112: 480 m, boost 695 m
5000 K
Dynamic Dual Position Light
Ref. no 50


Specifications
Type of lamp
LED
Pcs LED
18
Voltage
10-32V DC
Actual effect (W) 12V
R112: 76, boost: 133
Actual effect (W) 24V
R112: 75, boost: 157
Nominal current at 12V
R112: 6,35 A, boost: 11,05 A
Nominal current at 24V
R112: 3,13 A, boost: 6,54 A
Theoretical lumen (Lm)
18000
Actual lumen (Lm)
R112: 7040, boost: 9780
1 lux @
R112: 480 m, boost: 695 m
Kelvin (K)
5000
IP-class (IP)
IP68/IP69K
Beam pattern
Driving
Position light
dynamic white and amber
Connection
4-pin DT male + female
Cable length (mm)
2700
Material bracket
Stainless steel
Material chassi
Aluminum
Material lens
Polycarbonate
LxDxH (mm)
686×80,2×50
Height including bracket (mm)
61/63,9
Operating temperature
-40 – +60°C
E-mark approval
R112, R7
EMC
ECE R10
Ref. no
50
Weight (kg)
3
Warranty
5 years
EAN code
7333213101893
